LED lighting EMCOD ML50S12AC 50watt 12volt LED AC transformer driver indoor outdoor magnetic dimmable Class 2

LED lighting EMCOD ML50S12AC 50watt 12volt LED AC transformer driver indoor outdoor magnetic dimmable Class 2

More Views

LED lighting EMCOD ML50S12AC 50watt 12volt LED AC transformer driver indoor outdoor magnetic dimmable Class 2

Name: LED lighting EMCOD ML50S12AC 50watt 12volt LED AC transformer driver indoor outdoor magnetic dimmable Class 2
SKU: ML50S12AC
Price: 95.58 USD
Availability: InStock

# ML50S12AC

Be the first to review this product

LED lighting EMCOD ML50S12AC 50watt 12volt LED magnetic AC transformer driver is dimmable, black powder coated with both primary and secondary self-reset circuit breakers for indoor or LED lighting applications. 120volt input. Class 2.

Designer's Note

Our product designers and technicians want to remind you of the following: Magnetic lighting transformers are designed for 100% capacity (max. wattage). However we recommend using 80-85% of max. wattage, to be safe, due to varied lighting loads and types. Transformers require proper ventilation. The maximum ambient temperature should not exceed 50°C (122°F). If you insure that the temperature around transformer doesn't exceed 50°C (122°F) you can load transformer to 100% of operating capacity. Wire resistance, depending on gauge and length can be a factor in your lighting project performance and operation (voltage drop). Please use a qualified experienced electrician to install your lighting transformers.

SPECIAL ORDER ITEM CAN NOT BE RETURNED

Availability: Ships in 2-Business day!

$95.58

Qty:

Specification Sheets

ML50S12AC Spec Sheet

(Size: 185.5 KB)

Here to Help

Quality lighting can increase sales, security and property value.
Enjoy our video guides and how to's here

Details

EMCOD ML MAG-LED Series transformers are a Revolutionary Compact, dimmable, low profile magnetic LED Driver on the market. The transformer core and special low drop voltage rectifier are designed to lower losses and make the ML series very efficient and energy saving with low temperature rise. All the ML drivers have primary and secondary self-reset thermal circuit breakers, can be fully loaded and has excelled load regulation. Input and output are lead wires.

Additional Information

Color	Black
Warranty	90 Days
Important Note	SPECIAL ORDER ITEM CAN NOT BE RETURNED
Primary Breaker	Yes
Secondary Breaker	Yes
Circuits	Single
Terminal Block	Yes
Dimmable	Magnetic Dimmer - dimmer's minimum load must be maintained
Material	Steel
Cross Reference Number	MF50S12V, MF50S12AC, MF50S12VAC, MF50S12, ML50S12VAC
Application	Low voltage LED AC lighting
Approvals	cETLus
Max Load Wattage	50
Input Voltage	120VAC
Output Voltage	12VAC
Electric Current Type	AC
Dimensions H x W x L (in)	See Spec Sheet
