LED HD60-120 60watt 12VAC Electronic Encapsulated Transformer

# HD60-120

Be the first to review this product

LED Electronic 60watt bare wire replacement transformer. 120volt input, 12volt AC output. Compact easy to use design. Perfect for lighting applications. Dimmable with standard electronic dimmer. Similar to WAC-Lighting-EN-1260-R-AR. and the High-Tec Electronic Products part number TMO60S 120 20-60W E235548 transformer, SL-518
Ships Free by USPS 2-3 day from our parts department if 25 units or less are ordered. Do not order by air.

Availability: Typically ships same or next business day!

$11.00

Here to Help

Quality lighting can increase sales, security and property value.
Enjoy our video guides and how to's here
Details
Super small 120volt to 12volt AC completely encapsulated transformer. Output at 60watts max including line loss. Do not overload. Ships with 6" input and output leads. Please see specification sheet before you order.
Additional Information
Color Black
Warranty 90 Days
Important Note Ships Free by USPS 2-3 day from our parts department if 25 units or less are ordered. Do not order by air.
Primary Breaker No
Secondary Breaker No
Circuits Single
Terminal Block No
Dimmable Any dimmer
Material Plastic
Cross Reference Number SL-518 60 watt, SL-518, WAC-Lighting-EN-1260-R-AR, WAC EN-12P-AR, TMO60S 120 12-60W, TST-60, Top Star TST-60W/120V, Topstar TST-60W/120V, Ortek model CK-1260b-1, Novitronix 9801AR, Wang House Model WH-601E6A-3B
Approvals ETL
Max Load Wattage 60
Min Load Wattage 10
Input Voltage 120VAC
Output Voltage 12VAC
Electric Current Type AC
Dimensions H x W x L (in) 7/8" X 1-3/8" X 2-7/8"
