Quick outdoor landscape lighting 3M™ brown connector

Product Videos

  • How outdoor landscape lighting low voltage connectors work
  • 6 Top Outdoor Landscape Lighting Questions Answered

Quick outdoor landscape lighting 3M™ brown connector

# 3m 567-Connector

6 Review(s) | Add Your Review

Sign up for price alert

  •
3M™ Scotchlok™ electrical IDC run and tap, flame retardant, brown outdoor landscape low voltage connector. For use with 12 AWG (Tap) and 16-14AWG (Run) wire. This connector works the best with the #12, #14 and some #16 run wire and the smaller lead wires we now see installed with outdoor landscape LED fixtures. NOTE: two connectors required for each fixture. NOTE: TWO CONNECTORS required for one fixture. Order the total number of connectors required they do not ship in sets.

Designer's Note

Check your wire size, it is printed on the wire. Do not try to use this connector with #16 feed wire unless it has a oversize rubber insulation. Connector does not have Silicone Dielectric Grease like the blue connector. However it is a displacement connector and works very well in wet locations. If you want to protect the connector further you can find the grease at the big box stores in the electrical section or most any automotive store, just ask for "Silicone Dielectric Grease" This would be great protection in very wet areas. It is not made to bury in the ground, but place it under the ground cover. Watch out for old #12 wire that has been out in the weather for years. The rubber on this old wire may be to hard or to brittle to use. You may want to replace your wire.
Two connectors are required per fixture. Ships Free by USPS 2-3 day from our parts department
  • Buy 20 OR more for $0.59 each and save 10%
  • Buy 50 OR more for $0.54 each and save 17%
  • Buy 150 OR more for $0.52 each and save 20%
  • Buy 400 OR more for $0.49 each and save 25%

Availability: Ships in 2-Business day!

$0.65

Specification Sheets

pdf
567-Connector Spec Sheet
(Size: 239.6 KB)

Here to Help

Quality lighting can increase sales, security and property value.
Enjoy our video guides and how to's here
Details
Part of our complete line of outdoor landscape lighting fixtures, parts and fittings. Contact us with questions and design layout ideas. Electrically connects a (tap) wire end to a through (run) wire and insulates the connection. Flame retardant. Self-stripping. Used for tap splicing. Dual element connection. Maximum insulation O.D.diameter of 0.145 inches (3,68 mm) Tap, 0.190 inches (4,82 mm) Run and a operating temperature of 221°F (105°C). Flame retardant. Use to electrically connect a wire end (tap) to a through (run) wire and insulate the connection. Maximum insulation O.D.diameter of 0.190 inches (4,82 mm) and a operating temperature of 221°F (105°C). 3M Scotchlok Electrical IDC 567-BIN, Run and Tap, Flame Retardant, Brown, 18-14 AWG (Tap), 12-10 AWG
Additional Information
Color Brown
Warranty 90 Days
Important Note Two connectors are required per fixture. Ships Free by USPS 2-3 day from our parts department
Bulb Included No
Input Voltage 12
Voltage Type Low Voltage (12Volt)
Voltage 12
Application Connects fixture wire to main feed wire in a outdoor landscape lighting system
Cross Reference Number SP-CONN-BR, 3m 567 scotchlock
Material Plastic
UPC 054007148951
