Quick outdoor landscape lighting blue tap or run wire connector with moisture resistant gel 3M™ 804

# TLSP-BLUE-MR-CONNECTOR-804

Quick outdoor landscape blue wire connector, electrical IDC run and tap, moisture resistant gel and flame retardant. 3M™ 804. Accommodates 18-16AWG stranded landscape wire. Use with our 16AWG feed wire. works great with most fixture wire.

NOTE: TWO CONNECTORS required for one fixture. Order the total number of connectors required. Connector does not ship in sets.

Designer's Note

Due to the larger outside rubber coating of the #14guage wire it can no longer be used with this connector. ONLY the #18 or the #16 can be used. Some #16 wire has a slightly thicker outside insulation and you may have to force the wire into the connector, but it will work in most all cases. COLD weather. Do not install this connector if the wire, air and connector are under 55 degrees. Wait until they warm up. Some fixtures purchased on that huge global web site may not work as the lead wire from these substandard fixtures is so tiny the connector will not make contact.
FYI: Two connectors are required per fixture. Connector does not ship in sets. Ships Free by USPS 2-3 day from our parts department. ONLY use with #18 or #16 feed wire
  • Buy 20 OR more for $0.71 each and save 5%
  • Buy 50 OR more for $0.68 each and save 9%
  • Buy 100 OR more for $0.66 each and save 11%

Availability: Ships in 2-Business day!

$0.74

Here to Help

Quality lighting can increase sales, security and property value.
Enjoy our video guides and how to's here
Details
  • Blue, polypropylene-insulated connector is suitable to electrically tap into a wire in mid-span without cutting
  • Color-coded for quick and easy identification of the wire size
  • Suitable for control circuit wiring, fixture wiring, appliance wiring, signal and PA systems and automotive/boat/RV wiring
  • Accommodates 18 to 16 AWG stranded landscape wire or 14 AWG stranded standard insulated wire with maximum insulation diameter of 0.145 inches (3.68mm)
  • Brass element construction for good conductivity and tin plating for corrosion resistance
  • Withstands temperatures of 167 degrees F (75 degrees C)
  • Rated for 600V applications
  • UL Listed and RoHS 2011/65/EU Compliant

IDC Run or Tap Electrical Connector electrically connects a tap wire to a run (through) wire while insulating the connection. The connector insulation is manufactured from polypropylene and used to electrically tap into a wire in mid-span without cutting or stripping the wire. It is 600V-rated and withstands temperatures of 167 degrees F (75 degrees C).

IDC Run or Tap Electrical Connector is color-coded for quick and easy identification of the wire size required. The connector offers a moisture-resistant seal. This connector is suitable for control circuit wiring, fixture wiring, appliance wiring, signal and PA systems and automotive/boat/RV wiring. RoHS 2011/65/EU Compliant and UL Listed.

Do not use with #14 landscape wire from the big box stores. #16 varies in diameter and some may be larger or smaller and may require a small plyers to push into the connector.

Additional Information
Color Blue
Warranty 90 Days
Important Note FYI: Two connectors are required per fixture. Connector does not ship in sets. Ships Free by USPS 2-3 day from our parts department. ONLY use with #18 or #16 feed wire
Bulb Included No
Input Voltage 600V
Voltage Type Low Voltage (12Volt)
Voltage 12
Application Connects fixture wire to main feed wire in an outdoor landscape lighting system
Cross Reference Number 3M 804-BULK, 3M 804, 3M 804-BOX
Material Plastic
UPC 054007061342
Width (in.) 0.60"
Height (in.) 0.31"
Length (in.) 0.76"
